XC-623 Console

$4,765.00

The New XC-623 Source Sampler from Apex Instruments is designed for manual sampling of gaseous pollutants from stationary sources, e. g. stacks, flues, vents or pipes. The console is most commonly used for EPA Methods 6, 26 and VOST (Methods 0030 and 0031). However, it’s suitable for most sampling methods requiring accurate sample volume measurements at constant sample flow rates between 300 ccm to 5 LPM.

SKU: XC-623 Console Category:

Note: The images shown are for illustration purposes only and may not be an exact representation of the product.

Description

The metering console includes a precision dry gas meter fitted with a high-resolution rotary encoder, a leak-free pump, a vacuum gauge, flow control valves and a rotameter for monitoring the gas flow rate. A 32-bit microcontroller converts the sensor inputs and displays the totalized sample volume, temperatures and pressures into user selectable units. The transflective LCD display is sunlight-readable and backlit so it can be seen in the dark. Three advanced, self-tuning 1/32 DIN temperature controllers with individual solid-state relays are used for controlling heaters, e.g. probe, filter, and valve heaters.

The digital LCD screen displays the dry gas meter volume, elapsed time, the dry gas meter pressure (Pm), and the temperature of the selected thermocouple. A rotary switch is used for monitoring up to 6 different temperatures. Coarse and fine valves are used to control the sample flow rate and for adjusting the vacuum during leak checks. A quick connect provides a convenient connection for the sample vacuum line. An easy-to-use 4-button keypad is used to reset the gas volume and elapsed time at the start of each sample period along with other functions.

This console is housed in rugged and lightweight roto-molded linear low-density polyethylene (LLDPE/LMDE) case three stainless steel carrying handles.

Applicable US EPA Methods:

  • Method 4: Determination of Moisture Content in Stack Gases
  • Method 6: Determination of Sulfur Dioxide Emissions From Stationary Sources
  • Method 6A: Determination of Sulfur Dioxide, Moisture, and Carbon Dioxide From Fossil Fuel Combustion Sources
  • Method 26: Determination of Hydrogen Chloride, Halides and Halogens Emissions from Stationary Sources Non-Isokinetic
  • Method 0030: Volatile Organic Compounds (VOST)

Specifications:

Dry gas meter: SK25EX, multi-chamber positive displacement meter fitted with a quadrature encoder, Qmax for air, 4.1 m3/h at 220 Pa, Qmin 0.26 LPM, resolution 0.002 Liter, cyclic volume 0.7 liters, 400 pulses per revolution, accuracy 1.5% at volumes greater than 10 liters, type-K thermocouple for exit temperature

Display: 4×20 character back-lit transflective liquid crystal display, viewing area 74 mm x 45 mm, operating temperature -20 to 70⁰C

Flowmeter: precision stainless steel venturi orifice with a pressure transducer, range 0 – 5 inH2O (0-1245 Pa) resolution of 0.01 inH2O (1 Pa)

Internal sample pump: dual-head diaphragm, 8.0 LPM free flow, max vacuum 23 inHg (-230 mbar abs.), 12 VDC brushless motor

Temperature measurement: cold junction-compensated type-K thermocouple-to-digital converter °C/°F selectable, -200°C to 1372°C range. (-328°F to 2502°F). 6-channel rotary switch, up to 5 addition type-K thermocouple inputs, standard size jacks

Probe, filter, aux. temperature control: Fuji PXR3 compact, 1/32 DIN self-tuning PID temperature controller with 3-button keypad, solid-state driver for 25-amp solid state relay, type-K thermocouple jack for input

DGM pressure: high-resolution digital sensor, factory-calibrated, and temperature-compensated -20C to 70C, range bi-directional +/- 5.0 inH2O (+/-1245 Pa) with 0.001” (1 Pa) resolution, proof pressure 49 kPa, accuracy better than 0.25%

Vacuum gauge: Bourdon tube, dual-scale, 0 to -30 inHg, 0 to -100 kPa

Umbilical connection: electrical multi-conductor circular connector, instrumental grade stainless steel quick-connects for sample inlet: 1/4-inch, pitot connections: 1/4-inch, type-K thermocouples inputs: aux, stack, probe, oven, exit

Power: supply 120 VAC at 60 Hz 15 amps maximum or 240 VAC at 50 Hz 10 amps maximum, IEC C-13 inlet

Dimensions: H17” x W17” x D12” (43 cm x 43 cm x 30.5 cm)

Weight: 29.6 lbs (13.4 kg)



Additional information

Weight 45 lbs
Dimensions 19 × 13 × 19 in
Flow Meter

1 LPM, 2.4 LPM, 4 LPM

Unit Configuration

English Units, Metric Units

Voltage

120V, 240V
