Mercury Probe

$2,286.00 – $8,194.00

Apex Mercury Probes are manufactured using Alloy 276 for long-term or highly corrosive sampling applications like PS-12B and are designed to perform paired sampling using 10mm OD sorbent traps.



SKU: Mercury Probe Categories: , ,

Note: The images shown are for illustration purposes only and may not be an exact representation of the product.

Description

Apex Mercury Probes are designed for use with Apex mercury sorbent trap systems. Manufactured using Alloy 276 for long term or high corrosive sampling applications like PS-12B, the mercury probes are designed to perform paired sampling using 10mm OD sorbent traps. Optional Stainless Steel construction is available for short term sampling such as 30B or RATA testing.

 The sorbent traps are placed at the probe inlet to prevent Hg transportation losses during sampling.  The traps are sealed in place with compression fittings using glass-filled PTFE ferrules.

Features and Benefits

  • Single & dual heater configuration
  • Standard lengths available from 4 to 12 ft.
  • Custom lengths available upon request
  • Comes with Type K thermocouples and insulated junction enclosures

Additional information

Weight N/A
Dimensions N/A
Length

2 ft, 3 ft, 4 ft, 5 ft, 6 ft, 7 ft, 8 ft, 9 ft, 10 ft, 11 ft, 12 ft
Probe Material

Stainless Steel, Alloy C22/C276
Heater Option

Single Heater, Dual Heater
Voltage

120V, 240V
